PATANIYA WIRES & CABLES
Flame Retardant Low Smoke (FRLS) & Zero Halogen Low Smoke (ZHLS) Cables
Advanced fire-resistant cable solutions engineered for maximum safety, eco-friendly performance, and superior protection in residential, commercial, and industrial applications.
FRLS Protection
Low smoke emission with flame retardant safety.
ZHLS Eco Safe
Zero toxic halogen gas emission during fire.
High Safety
Designed for reliable and secure performance.
Industrial Grade
Suitable for industrial and heavy-duty usage.
FRLS Cables
Insulated with Flame Retardant Low Smoke (FRLS) PVC compound to achieve higher oxygen and temperature indices. These cables help restrict the spread of fire while ensuring low smoke density below 60%.
ZHLS Cables
Insulated with Zero Halogen Low Smoke (ZHLS) compound. These eco-friendly cables emit no toxic halogen gas and maintain very low smoke density below 20% during fire conditions.
Technical Data (FRLS / ZHLS)
| Nominal Area (mm²) | Conductor Structure | Insulation Thickness | Max DC Resistance | Current Rating |
|---|---|---|---|---|
| 0.75 | 24/0.20 | 0.6 mm | 26.0 Ω/km | 8 Amps |
| 1.0 | 14/0.30 | 0.7 mm | 18.1 Ω/km | 14 Amps |
| 1.5 | 22/0.30 | 0.7 mm | 12.1 Ω/km | 16 Amps |
| 2.5 | 36/0.30 | 0.8 mm | 7.41 Ω/km | 26 Amps |
| 4.0 | 56/0.30 | 0.8 mm | 4.95 Ω/km | 33 Amps |
| 6.0 | 84/0.30 | 0.8 mm | 3.30 Ω/km | 42 Amps |
